Thomson EF9345

The EF9345 from SGS-Thomson Microelectronics, Inc., was a semigraphic[1] microprocessor for video image control,[1] encapsulated in a 40-pin DIP and used primarily in the Matra Alice 32,[2] Matra Alice 90[3] and Philips VG5000 microcomputers.[4]

EF9345 pinout

It was compatible with the Motorola MC6847 and capable of displaying 8 colors (RGB primaries), 128 alphanumeric characters and 128 semigraphic characters.[5] It had one semigraphic mode, two text modes and eight graphic modes.[5] It was able to access 16KB of video RAM, although the Matra Alice hardware only used 8KB.

Video Modes
  • 50/60Hz output, interlaced or progressive scan
  • Semigraphics - 128 standard character set with 5x7 pixel font dimensions. User definable 8x10 pixel alphanumeric or semigraphic sets.
  • 40 characters x 25 rows text mode:
    • Selectable background and foreground colors
    • Styles: double height, double width, blinking, reverse, underline, conceal, insert, accentuation of lowercase characters
  • 80 characters x 25 rows text mode:
    • Styles: blinking, underlining, reverse, color
